The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.0 inch 128x64 LCD Graphic LCD Dot Matrix Module | STN Positive Yellow-Green Backlight | Arduino HTM12864-8B-11Y-A5P | Graphic LCD Module | 128x64 |
|
72.0x59.0x8.6 | 65.0x38.0 | 60.7x32.93 | 0.515x0.475 | 6H | YG | 17PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0 inch 128x64 LCD Graphic LCD Dot Matrix Module | STN Positive Display |Arduino | Gray Background Blue Text HTM12864-8B-11W-A5P | Graphic LCD Module | 128x64 |
|
72.0x59.0x8.6 | 65.0x38.0 | 60.7x32.93 | 0.515x0.475 | 6H | white | 17PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0 inch 128x64 LCD Graphic LCD Dot Matrix Module/DFSTN Negative/Black Background HTM12864-8B-41W | Graphic LCD Module | 128x64 |
|
72.0x59.0x8.6 | 65.0x38.0 | 60.7x32.93 | 0.515x0.475 | 6H | white | 17PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0 inch 128x64 LCD Graphic Dot Matrix Module | STN Negative Display | White Backlight | Arduino HTM12864-8B-25W | Graphic LCD Module | 128x64 |
|
72.0x59.0x8.6 | 65.0x38.0 | 60.7x32.93 | 0.515x0.475 | 6H | white | 17PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0 inch 128x64 LCD Graphic Dot Matrix Module | FSTN Positive Display | White Backlight | MCU | ST7565R HTM12864-8B-31W-A5P | Graphic LCD Module | 128x64 |
|
72.0x59.0x8.6 | 65.0x38.0 | 60.7x32.93 | 0.515x0.475 | 6H | white | 17PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0 inch 128x64 LCD Graphic Dot Matrix Module | STN Positive Display | Yellow-Green Backlight | Arduino HTM12864-8B-01Y-A5P | Graphic LCD Module | 128x64 |
|
72.0x59.0x8.6 | 65.0x38.0 | 60.7x32.93 | 0.515x0.475 | 6H | YG | 17PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 2.9 inch 128x64 LCD Graphic LCD Display Module | FSTN Positive RGB Backlight | Arduino | ST7565R HTM12864-8G-35S-A5P | Graphic LCD Module | 128x64 |
|
80x70x11.3 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | R/G/B | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 2.9 inch 128x64 LCD Graphic LCD Display Module | STN Positive Yellow-Green Backlight HTM12864-8G-11Y-A5P | Graphic LCD Module | 128x64 |
|
80x70x11.3 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | YG | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 2.9-inch 128x64 LCD Graphic LCD Display Module | STN Positive Film | 3.3V | MCU | Arduino HTM12864-8G-11W-A5P | Graphic LCD Module | 128x64 |
|
80x70x11.3 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 2.9 inch 128x64 LCD Graphic LCD Module | DFSTN Negative | MCU | Arduino | ST7565R HTM12864-8G-41W | Graphic LCD Module | 128x64 |
|
80x70x11.3 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R |
